28-Spindles scaffolding Rectangle Tube / Round Tube drilling Machine (Horizontal Type)

CF-3000D28H

Specifications:

1. With 14 Drilling Spindles on the machine¡¦s Left side: 4 set Drilling Spindles can be adjusted the pitch (175~250mm) by manual, the remain 10 set Drilling Spindles can not adjust the pitch (FIXED PITCH at 100mm)

2. With 14 Drilling Spindles on the machine¡¦s Right side: 4 set Drilling Spindles can be adjusted the pitch (175~250mm) by manual, the remain 10 set Drilling Spindles can not adjust the pitch (FIXED PITCH at 100mm)

3. Suitable Pipe Diameter: 1 1/2 inches to 6 inches

4. Hole pitch is changeable for the FRONT 4 set Drilling Spindles can be adjusted the pitch (175~250mm) on one side by manual. The remain 10 set Drilling Spindles in one side can not adjust the pitch (FIXED PITCH at 100mm)

5. You can have adoptability to change the number of holes (by removing the drilling bit) and diameter of holes (by changing the different diameter drilling bit) when you require by manual.

6. Pipe thickness: from 2mm to 10 mm mild steel

7. The Maximum Diameter of holes in the pipe: 18mm

8. Loading and Unloading the Pipe: Manual

9. The clamping is automatic: the working circle start with one button, loading and unloading manually.

10. Suitable Maximum Tube Length: 3000 mm

Major Parts/Components:

1. With Electrical Motors to drive the Drilling Spindles

2. With Morse Taper Drilling Bit (HSS [High Speed Steel] Material)

3. Coolant Motor : 1/4HP

4. Tube Clamping System :by Hudraulic Cylinder

Applications :

Scaffolding
