Steel ball slide assembly is a very unique job. There are several parts Rails, steel balls, ball retainer, plastic ball retainer, plastic bumper, plugs and grease, to be assembled in high speed and accurate. We have invested lots of effort in design and fabricate these steel ball assembly machine. And these assembly machine have become the most used and popular assemble machine for this kind. Most of ball bearing drawer slide manufacturer are using our ball bearing drawer slide assembly machines.

Ball Slide Automatic 3-Piece Slide Rails Assembly Machine

Cross Section of 3-Piece Ball Slide Rails
3-Piece Ball Slide Rails

Automatic Steel Ball Slide Assembly Machine

Section 1
1. Manually line up ball cage and middle rail
2. Pneumatic robot pushes ball cage through ball inserting device and assemble with middle rail. Before ball cage moves into middle rail, grease is spread to middle rail area.

Ball cage and middle rail assembled parts, moves forward through an intermittent conveyer

Section 2
Assemble plug on the rail, plug is supplied by vibration bowl.

Section 3
Assemble plastic strips and assembly outer rails
There are two plastic strip magazines, manually load plastic strips,
Robot will clamp middle rail, which has ball cage assembled, and move through plastic strip magazines.
Plastic strips will be assembled. And whole piece will go through ball inserting device and then assembled with outer rail

Section 4

Outer rail assembled part are moved by an intermittent conveyer to
Bending station where a hydraulic press will bend the end piece on outer rail,
Move the assembled part to next station and insert end plug, which is supplied by a vibration bowl.
Then finished slide will drop to conveyer and move out.

Features：

Can be freely adjusted for desired number of balls to be inserted
Automatically lubricates during assembly
Assembly Speed: 14 pcs/minute.

Ball Slide Semi-Automatic Slide Rails Assembly Machine

Cross Section of 2-Piece Ball Slide Rails
2-Piece Ball Slide Rails

Semi Automatic Steel Ball slide Assembly Machine

This semi automatic is good for small quantity operation, or 2 sections ball slides. The function of this semi-automatic ball slide assembly machine is to assemble following four elements together. (1) outer rail (2) ball cage (3) steel ball (4) greasing
Line up ball cage on right side material rack, and line up outer rail on right side material rack. Robot will bring the ball cage running through ball inserting device. Balls will be fed into cavities on ball cage. There is grease dispenser which will instill grease into the rail.

Features：

Can be freely adjusted for desired number of balls to be inserted
Automatically lubricates during assembly
Assembly Speed: 14 pcs/minute.

Samples:

We are dedicated in "Ball-Bearing Slide Rail Assembling Machines, Combination Jointers & Planers, Feeding Attachments, Brake Cable / Steel Rope Welding Machines." with operations in Taiwan.

We can design and manufacture slide assembly machines in accordance with customer samples and requirements.

Main Products/Service: Ball-Bearing Slide Rail Assembling Machines, Combination Jointers & Planers, Feeding Attachments, Brake Cable / Steel Rope Welding Machines., 46mm Slide Inner-Plate Assembly Machine, Three-Sectional Slide Assembly Machine, Two-Sectional Slide Assembly Machine

We are a professional machine manufacturer, turning out mainly ball-bearing slide rail assembly machines, combination jointers & planers, feeding attachments, brake cable & steel-rope welding machines, slide inner-plate assembly machines, etc. We are also manufacture full range of Automatic Assembly Machines, such as custom-designed CNC lathe, Horizontal Multiple Spindle Drilling Machine, NC Twin Spindle Upright Deep Hole Drilling Machine, Rotary Type 6-Station Drilling and Tapping Machine, Single Spindle Recessing Machine, etc. all of our automatic assembly machines are manufactured precisely, automatic assembly machines manufactured by us has been controlled strictly in producing and processing management.

With conscientious dedication to R & D, the company can design and manufacture various slide assembly machines in accordance with the demands and requirements of customers, and is reputed as one of the most seasoned makers in the machinery industry in Taiwan.

Currently the company is actively promoting a three-sectional slide assembly machine, which can be freely adjusted for inserting desired number of balls and automatically lubricate during assembling.
