Automatic Polygon Machine

CFSY-400

¡@

Feature:

1.The machine can set full-automatic or half-automatic.

2.Automatically operate, and the machine will automatically stop working while breaking down.

3.Product can be customized.

Specifications:

Specifications

CFSY-400

workpiece diameter

4~40 mm

workpiece length

25~400 mm

workpiece type

Hexagon, Octagonal, Square

output ( pcs / per min)

2~3

Main Motor (Hydraulic)

3HP

system used

Hydraulic System

Machine net weight

1250 Kg

Machine Size (L x W x H)

1800x1800x2000 mm

¡@

Workpiece Diameter

8 ~ 70 mm
Workpiece Length

100 ~ 1200 mm
Workpiece Type

hexagon . round .square
 Output(pce/per min)

1 ~ 2
Horse Power

10 HP
System Used

Hydraulic System
Machine Dimensions (LxWxH)

3000 x 2500 x 2500 mm
Net Weight

2500 KG
