16 Spindles Multi-Axis Pipe / Drum Drilling Machine (Horizontal Type)

CFPDM-12000-16S



Feature:

The Pipe is moved by SERVO MOTOR in the forward direction and backward direction.

Rotation the pipe by SERVO MOTOR.

There is 1 set Drilling Base in this machine. 16 sets Drilling Spindles in one Drilling Base. So there are total 16 sets Drilling Spindles in this machine.

Automatic Feeding Device with Clamping Chuck.

Automatic PLC Electrical Controll Box with TFT HMI .

Specifications:

ITEM @
Drilling Spindle Head 16 sets
Transmission Electrical Motor: 3HP 16 sets
Frequency Transformer 16 sets
Drilling Guide Socket 16 sets
Forward/Backward Feeding System 2 sets
Tube Holder (Left & Right) 1 set
Cooling Water Pump 2 sets
Clamping Mold 1 set
Hydraulic System:1HP20L 16 sets
Automatic Control Box (PLC Type) 1 set

Machine Layout:

Applications :

Oilfield Services Industry
