LOW-HEADROOM TYPE
¡@
|
LOW-HEADROOM TYPE |
|
¡@ |
 |
DIMENSION(mm) | ||||||
| Model | A | B | d | D | h | H | |
| HCW02 | 710 | 580 | 120 | 147 | 45 | 65 | |
| HCW05 | 920 | 650 | 150 | 178.5 | 45 | 65 | |
| HCW07 | 1200 | 650 | 170 | 200 | 46 | 75 | |
| HCW10 | 1400 | 650 | 180 | 210 | 52 | 80 | |
| SPECIFICATIONS | ||||||||||
| Model | Code | Nominal Capacity (kg) | Traversing Speed(m/min) | Traversing Speed (m/min) | ||||||
| Out Put(kw) | Duty Rating | 50HZ | 60HZ | |||||||
| Single Speed | Dual Speed | Single Speed | Dual Speed | (ED%/S/H) | Single Speed | Dual Speed | Single Speed | Dual Speed | ||
| HCW02 | HCW02A1 HCW02B1 HCW02C1 | HCW02A3 HCW02B3 HCW02C3 | 2000 | 0.13 | 0.13/0.04 | 30/250 | 17.8 20.5 24.6 | 17.8/5.9 20.5/6.8 24.6/8.2 | 21.3 24.6 29.5 | 21.3/7.1 24.6/8.2 29.5/9.8 |
| HCW05 | HCW05A1 HCW05B1 HCW05C1 | HCW05A3 HCW05B3 HCW05C3 | 5000 | 0.25 | 0.13/0.04 | 21.8 25.1 30.1 | 21.8/7.3 25.1/8.4 30.1/10.0 | 26.1 30.1 36.1 | 26.1/8.7 30.1/10.0 36.1/12.0 | |
| HCW07 | HCW07A1 HCW07B1 HCW07C1 | HCW07A3 HCW07B3 HCW07C3 | 7500 | 0.50 | 0.13/0.04 | 20.9 24.1 29.0 | 20.9/7.0 24.1/8.0 29.0/9.6 | 25.1 29.0 34.8 | 25.1/8.4 29.0/9.6 34.8/11.6 | |
| HCW10 | HCW10A1 HCW10B1 HCW10C1 | HCW10A3 HCW10B3 HCW10C3 | 10000 | 0.50 | 0.13/0.04 | 20.3 23.4 28.1 | 20.3/6.8 23.4/7.8 28.1/9.4 | 24.3 28.1 33.7 | 24.3/8.1 28.1/9.4 33.7/11.2 | |
¡@
|
|
